Radio Testing for Global Market Access
Regulatory and performance testing for wireless devices.Including accredited radio frequency and compliance testing across all major markets.
Regulatory Compliance & Performance Testing
RF Expertise & Wireless Technologies
IB-Lenhardt AG provides accredited radio frequency testing in ISO/IEC 17025 environments, delivering internationally recognized conformity assessment. Our laboratories cover all relevant frequency bands up to 500 GHz and support both regulatory approval and performance validation.
We measure and analyze RF signals across a wide range of wireless technologies, including Wi-Fi / WLAN, Bluetooth, cellular systems, Ultra-Wideband (UWB), radar sensors, GNSS receivers, wireless power transmission, and DAB/DVB.
Beyond regulatory testing, we also qualify devices under private industry schemes such as Bluetooth® SIG, NFC Forum, and the Qi / Wireless Power Consortium.
Certification Scope
Our RF testing supports conformity assessment under major international radio regulations. We evaluate all essential RF parameters and regulatory requirements needed for CE (EU RED), FCC, ISED, MIC, and more than 200 additional global markets. These requirements apply to telecommunications equipment and wireless communication devices.
Regulatory Frameworks
- EU Radio Equipment Directive (RED)
- FCC Part 15 and US authorization rules
- ISED Canada Radio Standards
- Japanese Radio Law
- Additional regional requirements across EMEA, the Americas, and APAC
RF Compliance Parameters
- Transmit power, power levels, and spectral usage
- Occupied bandwidth (OBW)
- Spurious emissions and unwanted radiation
- Duty-cycle and spectrum access limits
- Harmonized or local spectrum requirements
Approval Pathways
- EU Declaration of Conformity under RED
- FCC Certification via TCB
- ISED Certification via FCB
- MIC Certification via RCB
- Additional authorization schemes for 200+ jurisdictions
The combination of regulatory frameworks, RF compliance parameters, and approval pathways forms the basis for applying the correct radio standards. Key standards for wireless devices are outlined in the Standards section and further explained in our Knowledge Base.
The RF Testing Process
A structured workflow from initial request to approval — supported by ISO/IEC 17025 accredited RF testing.
RF Test Laboratory
Our laboratory infrastructure supports accredited RF testing across the full frequency range relevant to modern wireless devices, using calibrated test equipment.
Core Capabilities:
Semi-anechoic chambers for radiated RF measurements
Conducted RF setups for wideband and narrowband technologies
Signal analyzers and vector signal generators up to 500 GHz
Shielded rooms for sensitive receiver and coexistence testing
Automated test systems for Wi-Fi, Bluetooth, UWB, radar and GNSS
All measurements are performed using ISO/IEC 17025–compliant procedures. We also support EMI and EMC testing for devices requiring broader electromagnetic compatibility assessment.
Radar Performance Testing
Radar performance testing extends the regulatory RF scope with application-specific measurements for automotive and industrial radar systems. These evaluations ensure reliable sensor operation under real-world conditions and verify both functional and regulatory performance requirements in diverse RF environments.
Radar-Specific Test Capabilities
3D antenna and radiation pattern measurements
Radar echo simulation across distance and velocity scenarios
Output power and waveform verification for radar transmitters
Receiver robustness testing under in-band and out-of-band interference
Radome characterization, including EIRP comparison with and without radome
These performance tests are particularly relevant for advanced driver assistance systems and industrial sensing applications, ensuring reliable radar operation in safety-critical environments.
Let's get in Touch
The experts at IB-Lenhardt AG and IBL-Lab GmbH are always there for you. Just contact us!Key RF Standards & Regulations
European Union
-
2014/53/EU — Radio Equipment Directive (RED)
- Essential requirements for radio equipment.
-
ETSI EN 300 220
- Short-range devices in 25 MHz–1 GHz.
-
ETSI EN 300 328
- 2.4 GHz wideband systems (Wi-Fi, Bluetooth, proprietary RF).
-
ETSI EN 302 065 Series
- Ultra-Wideband (UWB) devices.
-
ETSI EN 301 908 Series
- Cellular LTE / 5G NR.
-
ETSI EN 303 687
- 6 GHz Wi-Fi 6E / Wi-Fi 7.
-
ETSI EN 300 330
- 9 kHz–30 MHz SRD incl. NFC/RFID.
-
ETSI EN 301 893
- 5 GHz RLAN incl. DFS / TPC.
-
ETSI EN 303 413
- GNSS receivers (GPS, Galileo, GLONASS, BeiDou).
-
ETSI EN 302 264 / EN 303 396
- Automotive short-range radar (76–81 GHz).
FCC Standards (United States)
-
FCC Part 15
- Unlicensed RF devices (Wi-Fi, Bluetooth, UWB, SRD).
-
FCC Part 22 / Part 24 / Part 27
- Cellular, PCS, LTE, 5G NR incl. AWS, WCS, CBRS.
-
FCC Part 95
- Personal Radio Services.
-
FCC Part 90
- Private land-mobile / industrial RF systems.
-
FCC Part 30
- mmWave 5G (Upper Microwave Flexible Use).
-
FCC KDB Publications
- Measurement guidance for SAR, RF exposure, DFS, UWB and device-specific test cases.
International
-
Canada: ISED RSS-Gen
- General requirements for radio apparatus.
-
Canada: ISED RSS-247
- Licence-exempt Wi-Fi, Bluetooth and 2.4/5 GHz devices.
-
Japan: MIC Radio Law
- Certification requirements for Specified Radio Equipment.
-
Japan: ARIB STD-T66 / T71 / T108
- Technical standards for 2.4/5 GHz WLAN and UWB.
-
China: SRRC Type Approval
- Mandatory RF approval for transmitting equipment.
-
South Korea: RRA Radio Regulations
- Requirements for WLAN, UWB and short-range devices.
Explore More RF Standards & Test Requirements
Our Knowledge Base offers a comprehensive, searchable overview of global RF standards, structured by the Americas, EMEA, and APAC regions. The table provides detailed information on technologies, frequency ranges, and approval notes across all major radio regulations worldwide.
Technical Insights for Wireless Devices
Our RF testing services are supported by a comprehensive technical knowledge base that covers essential measurement principles and radio performance topics relevant to wireless devices in real operating environments.
Key Technical Areas:
Transmit Characteristics: EIRP/ERP methods, peak vs. average power, time-domain behavior
Spectrum Analysis: Modulation properties, channel occupation, spectral masks, frequency stability
Spurious Domains: Harmonics, intermodulation products, unwanted emissions
Wireless Coexistence: DFS behavior, TPC, interference mechanisms, coexistence strategies
Specialized Technologies: Automotive radar (76–81 GHz), Bluetooth LE, Wi-Fi 6/7, UWB pulse shaping, WPT/Qi
Further technical explanations, glossaries, and engineering tools can be found in our Knowledge Base. It also provides guidance for common use cases and broader communications systems.
Contact Us
Regulatory & Performance Wireless Testing
We provide accredited RF testing and global approval support to help bring your wireless products to international markets efficiently and with full regulatory confidence. The experts at IB-Lenhardt AG and IBL-Lab GmbH are available to assist with technical questions, project planning, and testing requirements.
